關於翔崴

本公司專門從事半導體電子零件之代理銷售業務，特別著重在影像方面，遠端監控及保全系統 CCTV 方面的整合，已累積了相當多的經驗與技術，並代理多項產品，可運用於各種不同領域的電子產品。

NEXTCHIP：	專業於 CCTV ICs，並可提供客戶如Analog HD、 Mega Pixel CMOS ISP、 CAR Rear camera ISP、Video Decoder 等 Solution。
SHINKOH：	專業於光感測器（光遮斷器），可適用於紙鈔辨識機器、錢幣兌換機器、多功能事務影印機器、大型遊戲機、自動販賣機器及工業機器等產品，應用於物體、銅板、油墨、BAR CODE 及記號等的偵測與辨別。
NEOWINE：	鎖碼 IC 的專家，其鎖碼 IC 配合韌體可以防止電路被複製，用於 DVR、Set top box、手機、數位相機等等的電子產品上及Segment LED driver。
ZEEANN：	CMOS Sensor的專業製造，目前有1080P、720P & VGA CMOS sensors，1080P sensor 內含ISP, OSD & MCU，用於 Security、Surveillance、Automobile Cameras & IP Cameras等的CCTV電子產品上。
ROTAC：	Slip Ring(集電滑環)等產品。

本公司會持續深耕這些方面的技術，以提供更好的服務於客戶，希望能有機會為您服務。謝謝！

公司沿革

2014.04	遷移至新北市新店區營業。
2013.06	取得 ROTAC 產品代理權。
2012.02	取得 ZeeAnn 產品代理權。
2008.11	取得 Neowine 產品代理權。
2006.10	取得 Shinkoh 產品代理權。
2006.07	遷移至汐止遠東科技中心，擴大營業。
2004.10	公司成立，代理 Nextchip 產品

最新消息

【NEXTCHIP】	產品資訊	說明
NVP2440H/NVP2441H	The brand new megapixel CMOS ISP, NVP2440H/NVP2441H has state-of-the art technology to give the best image quality ever. Especially it is designed to meet the demands of new trend in CCTV market, both Analog HD Camera and cost-effective HD-SDI applications.The main concept of NVP2440H is supporting 2.0M CMOS sensor and output I/F as digital 1080p, AHD 2.0(1080p)/AHD 1.0(720p) and HD-SDI 720p. NVP2441H is supporting 1.3M CMOS sensor and output I/F as analog AHD 2.0(1080p)/AHD 1.0(720p)/1280H(CVBS/COMET).
NVP6114A	NVP6114A includes 4-Channel AHD1.0 RX and 9-Channel Audio Codec. 4-Channel AHD1.0 RX delivers high quality images. It accepts separate 4 CVBS/COMET/AHD1.0 inputs from Camera and the other video signal sources. It digitizes and decodes NTSC/PAL/COMET/AHD1.0 video signal into digital video signal which represents 8-bit BT.656/BT.656like 4:2:2 byte interleave format with 54/72/108/144MHz multiplexed. Especially, It is able to use same transmission cable with conventional one for COMET(SD level) and AHD 1.0 (HD level), and they provide the superior image quality by minimizing the interference when separating Y and C. 9-Channel Audio Codec is 8-Channel Voice/1-Channel Mic PCM Codec which handles voice band signals(300Hz~3400Hz) with 8bit/16bit linear PCM, 8bit G.711(u-law, a-law) PCM. Built-in audio controller can generate digital outputs for recording/mixing and accepts digital input for playback. 4-Channel Coaxial Communication Protocol communicates between controller(DVR) and camera on the video signal through coaxial cable. COMET is Composite Video of Enhanced Technology in SD video by NEXTCHIP. AHD is a video transmission technology in HD video by NEXTCHIP.
NVP6124	FHD AHD™ DVR RX CVBS/COMET/AHD 1.0/AHD 2.0 Simultaneous Input Up to 4CH 1080p@25/30fps NVP6124 is a RX chip belonging to the AHD2.0 product family. It provides DVR solutions with FHD 4CHs. It offers system-friendly development environment so that users can easily configure input formats out of CVBS, COMET AHD1.0 or AHD2.0 per channel. To ensure image quality under coax environment, advanced signal filtering technology is applied. It also comes with user-friendly RDK.
NVP6021	NVP6021 is high speed, digital-to-analog video encoder in a 40-eQFN package 3.3 V, video DAC provides support for composite AHD2.0 analog outputs in high definition (HD) video formats. NVP6021 has a 16-bit video input port that can be configured in a variety of ways. Video input data can be supplied in the YCrCb 4:2:2 color space. NVP6021 also supports embedded EAV/SAV timing codes, and I2C communication protocol. AHD2.0 Technology AHD2.0 is a video transmission technology in high definition via coaxial cable. AHD2.0 offer specifications - 1080p(1920x1080); which are compatible with the industrial standard 1080p.
NVS2700	Resolution up to 1280x720p@60fps Automotive Front/Rear/Side Camera Ethernet AVM System NVS2700 provides a highly reliable solution for automotive Ethernet AVB camera systems. It is the most compact & cost-effective Ethernet camera SoC optimized for automotive needs. With embedded Low-Latency H.264 Codec, Ethernet AVB MAC controller and megapixel ISP, NVS2700 facilitates high performances for time-sensitive applications.
NEXTCHIP NVP2410/NVP2421	Megapixel CMOS sensor ISP, NVP2410/NVP2421 supports most of the output formats for full HD IP camera, 3G-SDI(HD CCTV) and high-end analog CCTV application. It is with embedded fast 8051 MCU and SDRAM. It receives 12bit parallel or sub-LVDS CMOS sensor inputs and provides Hi-spy, BT.1120, YC 16bits and composite video outputs. These include WDR, 3D-NR, Smart digital zoom, electronic PTZ, day & night, frame rate conversion(FRC), flicker suppression, high light compensation(HLC/BLC), privacy zone masking, motion detection, IRIS control I/F, OSD, etc
【ZEEANN】	產品說明	說明
ZEEANN ZA20S10	ZA20S10是智眼公司開發的最新專利產品, 該高畫質傳感器設有低噪音高速電路含有ISP & OSD, Full HD(1080P)支持30fps錄影,Non-mobile 1/3" optical format 分辨率為1920x1088P(16:9), 可應用於Full HD SDI camera, AHD camera, TVI camera IP camera and Car DVR 等.
【ROTAC】	產品說明	說明
ROTAC SRS1202	SRS1202 series Slip ring provides 6/12/18 circuits, Gold to gold contact, superior for low singals, Compact size diameter
【NEOWINE】	產品說明	說明
NEOWINE ALPU-C	ALPU-C provides 3.3V,Built-in POR,SOC,Cipher Algorithm：Applied AES-128,192bits OTP Memory, Built-in RTC with Two Alarm Events, Built-in IR Receiver (Compatibility with NEC Format), Various GPIO Functions (Reset/Switch/Interrupt/PWM/GPIO), Package Type：SOT-23F
【SHINKOH】	產品說明	說明
SHINKOH KI1400	KI1400 為新光電子最新型感測器，可應用的產品例如：讀卡機、自動販賣機、售票機、多功能事務機，歡迎來電洽詢。
【Lofty】	產品說明	說明
人才募集	歡迎熱誠歡迎具有『主動積極』、『熱誠』、『耐壓性強』的人才加入我們的行列。
